• information



A fruit and vegetable pulp machine is a device specifically used for processing fruits and vegetables, converting them into pulp or mud like products. It can be used to produce jam, juice, seasonings, salad dressings, etc.


The working principle of the fruit and vegetable pulping machine is as follows:
Feeding system: fruits and vegetables are fed into the pulp machine through the feeding port.
Cutting system: Using blades or pressure to cut fruits and vegetables for better crushing and mixing.
Pre processing system: Depending on the type of fruit and vegetable, it may be necessary to perform pre processing steps such as peeling, removing seeds, and removing kernels.
Crushing system: Use high-speed rotating blades or mixers to crush and stir fruits and vegetables, making them in a slurry or muddy state.
Separation system: separates the pulp or mud like substances of fruits and vegetables from solid residues, usually achieved through a sieve or centrifugal force.
Collection system: Collect the separated pulp of fruits and vegetables, which can be further processed or packaged.


The advantages of fruit and vegetable pulping machines include:
Improving production efficiency allows for rapid processing of large amounts of fruits and vegetables.
Preserving the nutritional ingredients and taste of fruits and vegetables, making the products more fresh and natural.
It can adapt to different types of fruits and vegetables and has strong versatility.


For some fruits and vegetables with skin or core, the fruit and vegetable pulping machine can conveniently perform pre-treatment.
It should be noted that different fruit and vegetable pulping machines are suitable for different types of fruits and vegetables, as well as different processing requirements. When choosing a fruit and vegetable pulping machine, it is necessary to consider factors such as raw material characteristics, processing capacity, cleanliness and hygiene requirements, as well as the reliability and stability of the equipment.


Application:

Usage: this machine can be used topulp on the following fruits;
stonefruits after the stone has been removed, such as mango, peach, apricot, date;
Alsoused for the baccas (Chinese goosebeery and strawberry);
kernelfruits after been cooked and softened(such as apple,pear,pumpkin)
Characteristics:
fruitpulp and the dreg separate automatically;
canbe mounted in a processing line, and also can perform the production by its own.
Allthe material where contact with the product is made of high quality stainlesssteel which meet the standard of food requirements.
Easyto clean and disassemble and assemble.
Technicalparameter:



Model

Description

External  dimension(mm)

(L*W*H)


Suggested capacity

Suggested power

capacity and power varies as to

different fruits

DDJ-2


All  made of sus304 stainless steel, rotating at 960-1350 rpm


1170*600*1250

≤2(T/H)

5.5

DDJ-5

1760*800*1500

3~5(T/H)

15

DDJ-10

1950*1050*1880

6~10(T/H)

22

DDJ-15

2150*1050*1880

11~15(T/H)

30
