• information


The Bottle Tilting Sterilization Chain is a type of sterilization process used in the food and beverage industry to ensure the safety and quality of products.

This method involves a conveyor system with a series of specially designed bottle holders that securely hold the containers in an inverted position. The bottles are tilted to a specific angle, allowing for efficient and thorough sterilization.

The sterilization process typically involves the use of hot water or steam. The bottles are subjected to high temperatures for a predetermined period of time, which effectively kills any bacteria, viruses, or other harmful microorganisms present on the surfaces of the bottles.

The tilting motion of the chain ensures that all parts of the bottle, including the neck and cap, come into contact with the sterilizing agent, leaving no area untreated.

After the sterilization process is complete, the bottles are returned to an upright position and can proceed to the next stage of production, such as filling, capping, or labeling.

The Bottle Tilting Sterilization Chain offers several advantages over other sterilization methods. It is highly effective in eliminating microorganisms, ensuring product safety. The tilting action allows for better coverage and penetration of the sterilizing agent, resulting in more thorough sterilization. Additionally, the process is efficient and can handle a large volume of bottles in a continuous manner, improving productivity.

Overall, the Bottle Tilting Sterilization Chain is a critical component of the food and beverage industry's efforts to maintain high standards of product quality and safety.


Technical advantages:

Continuous Bottle Tilting Sterilization chain is designed by absorbing technology of same procedures from foreign model machine. Main characteristic: stable conveying without shaking and jumping. The products are tilting upended on the sterilization chain , of which the lean angle is not more than 93 degree to ensure full effectiveness. The machine has the advantages of conveying smoothly, beautiful shape and little noise etc. its linear velocity is  0M-15M/min, sterilization time is 25s-60s,motor adopts conversion motor.


Techncial Data:


Model

LPL-6000

LPL-10000

LPL-12000

LPL-15000

LPL-18000

Line speed

0M-15M/min,(stepless adjusting)

Total power(kw)

1.1

1

13.6

16.5

25

External length(m)

7.6

10

12

15



Condition: New
Brand name: Shanghai Beyond;
Type: whole processing Line/turnkey project/fruit and vegetables processing/dairy processing/beverage processing
Voltage: 220v/380v
Power(W): 100-200kw
Weight: Different size different weight/customized
Dimension(L*W*H): Different size different dimension/customized
Certification: CE&ISO9001
Warranty: 12 months/1 year
After-sales Service Provided: Engineers available to service machinery overseas
Main material: SUS304 or SUS316
Control type: automatic, semi-automatic
energy consumption: Low consumption with high efficiency
capacity: 500-10000L/H-customized
installation period: 1-3months
Period time: 30 days-120 days
Cups material: pouches, paper box, glass bottle, pet bottle, glass bottle
Product storage condition: room temperature; low temperature;
